Case
Kobelco
SK260LC-9
Excavator
63 specifications
1 / 5
Image 1 of 5
Specifications
55 data points
Operating Specifications
| Operating Weight | 153,300 lb |
|---|---|
| Fuel Capacity | 238.0 gal |
| Hydraulic Pump Flow Capacity | 105.7 gal/min |
| Hydraulic System Fluid Capacity | 172.0 gal |
| Hydraulic System Relief Valve Pressure | 4,554 psi |
| Engine Oil Capacity | 13.7 gal |
| Cooling System Fluid Capacity | 29.6 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 7.1 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | AH-6WG1X Tier III certified |
|---|---|
| Displacement | 957 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 425.0 hp |
| Aspiration | turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 1,460 lb-ft |
Dimensions
| Ground Clearance | 384 in |
|---|---|
| Height - Top of Cab | 150 in |
| Length of Track on Ground | 186 in |
| Tail Swing Radius | 158 in |
| Width to Outside of Tracks | 143 in |
| Removal Counterweight Clearance | 708 in |
Undercarriage
| Ground Pressure | 11 psi |
|---|---|
| Track Gauge | 128 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 2.5 mph |
| Shoe Size | 36 in |
| Number of Shoes per Side | 47 |
| Number of Carrier Rollers per Side | 3 |
| Drawbar Pull | 10,543 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 389 in |
|---|---|
| Max Reach Along Ground | 204 in |
| Max Loading Height | 343 in |
| Max Vertical Wall Digging Depth | 341 in |
| Max Cutting Height | 500 in |
| Shipping Length of Unit | 520 in |
| Shipping Height of Unit | 204 in |
Bucket
| Maximum Bucket Capacity | 6.00 yd³ |
|---|---|
| Minimum Bucket Capacity | 2.60 yd³ |
Swing Mechanism
| Swing Speed | 7 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 354 in |
|---|---|
| Max Vertical Wall Digging Depth | 291 in |
| Max Cutting Height | 474 in |
| Max Loading Height | 322 in |
| Max Reach Along Ground | 528 in |
| Shipping Length of Unit | 523 in |
| Shipping Height of Unit | 176 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 330 in |
|---|---|
| Max Cutting Height | 469 in |
| Max Loading Height | 317 in |
| Max Vertical Wall Digging Depth | 270 in |
| Max Reach Along Ground | 509 in |
| Shipping Length of Unit | 523 in |
| Shipping Height of Unit | 170 in |
