Case
Kobelco
SK260LC-9
Excavator
63 specifications
1 / 5
Image 1 of 5
Specifications
79 data points
Operating Specifications
| Operating Weight | 158,292 lb |
|---|---|
| Arm Breakout Force | 63,621 lb |
| Arm size | 139,764 in |
Engine
| Engine Model | Isuzu 6 WG1 |
|---|---|
| Displacement | 952 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 460.0 hp |
| Max Torque | 1,623 lb-ft |
| Engine Make | Isuzu |
| Stroke | 6 in |
| Bore | 6 in |
| Fuel Type | Requires ultra-low sulfur fuel B5 biodiesel tolerant |
| Emission Tier Level | Tier 4 |
| Fuel injection | Direct injection - electronic |
| Air filter type | Dry type element with warning restriction indicator |
| Fuel Filter | Replaceable full flow spin-on cartridge |
| Oil Filter | Replaceable full flow spin-on cartridge |
Weights
| Counterweight | 22,928 lb |
|---|
Hydraulic System
| Main pump - Maximum flow | 2,218.9 gal |
|---|---|
| System relief pressure | 4,550 psi |
Dimensions
| Ground Clearance | 33 in |
|---|---|
| Tail Swing Radius | 159 in |
| Overall Height | 170 in |
| Track Shoe Width | 36 in |
| Cab height | 138 in |
| Center to center - idler to sprocket | 186 in |
| Ground pressure | 11 psi |
| Boom length | 305 in |
| Minimum ground clearance | 33 in |
Transmission
| Max Speed | 2.7 mph |
|---|
Undercarriage
| Track Shoe Width | 36 in |
|---|
Brakes & Steering
| Service brake | SAHR disc - each motor |
|---|---|
| Brakes Type | Mechanical disc |
| Travel control | Dual stage relief or counter balance design |
Fluid Capacities
| Fuel Tank | 62.9 gal |
|---|---|
| Hydraulic system | 171.8 gal |
| Hydraulic Tank | 81.9 gal |
| Cooling system | 28.6 gal |
| Engine oil w/ filter change | 13.8 gal |
| Swing drive | 3.6 gal |
| Final Drive | 39.7 gal |
| DEF Tank | 40.2 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 331 in |
|---|---|
| Max Reach Along Ground | 515 in |
| Max Vertical Wall Digging Depth | 256 in |
| Minimum swing radius | 229 in |
| Bucket rotation | 175 ° |
| Mximum dig radius | 515 in |
| Dig radius at ground line | 504 in |
| Dump height | 308 in |
General Specifications
| Operating Weight lbs (kg) | 159,600 (72,400) — Starting 2025 Model Year |
|---|---|
| Digging Depth ft (m) | 24.2 (7.2) — Starting 2025 Model Year |
| Digging Reach ft. (m) | 37.9 (11.4) — Starting 2025 Model Year |
| Engine hp (kW) | 460 (343) — Starting 2025 Model Year |
Swing Mechanism
| Swing Speed | 7 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Vertical Wall Digging Depth | 270 in |
|---|---|
| Minimum swing radius | 230 in |
| Bucket rotation | 175 ° |
| Dig radius at ground line | 503 in |
| Dump height | 304 in |
| Maximum dig radius | 503 in |
| Maximum reach height | 476 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 354 in |
|---|---|
| Minimum swing radius | 226 in |
| Overall height | 170 in |
| Bucket rotation | 175 ° |
| Maximum dig radius | 537 in |
| Dig radius at ground line | 527 in |
| Dump height | 349 in |
| Maximum reach height | 471 in |
Boom/Stick Excavator Option 4
| Max Vertical Wall Dig Depth | 325 in |
|---|---|
| Minimum swing radius | 225 in |
| Bucket rotation | 175 |
| Dig radius at ground line | 560 in |
| Dump height | 331 in |
| Maximum dig radius | 568,899 in |
| Maximum reach height | 484 in |
Performance
| Lift over end Max. reach | 21,164 lb |
|---|---|
| Lift over side Max. reach | 13,536 lb |
