Caterpillar
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
Caterpillar
229
- Operating Weight
- 69,468 lb
- Max Digging Depth
- 288 in
- Max Digging Depth
- 312 in
- Net Power
- 180.0 hp
1 / 5
Image 1 of 5
Specifications
47 data points
Operating Specifications
| Operating Weight | 69,468 lb |
|---|---|
| Fuel Capacity | 65.0 gal |
| Hydraulic Pump Flow Capacity | 121.0 gal/min |
| Hydraulic System Fluid Capacity | 151.9 gal |
| Hydraulic System Relief Valve Pressure | 3,800 psi |
| Engine Oil Capacity | 3.3 gal |
| Cooling System Fluid Capacity | 10.1 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 7.6 gal |
| Alternator Supplied Amperage | 35 A |
Engine
| Engine Model | 3208 |
|---|---|
| Displacement | 635 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 180.0 hp |
| Aspiration | Turbocharged |
Dimensions
| Ground Clearance | 23 in |
|---|---|
| Height - Top of Cab | 133 in |
| Length of Track on Ground | 179 in |
| Tail Swing Radius | 115 in |
| Width to Outside of Tracks | 137 in |
| Removal Counterweight Clearance | 49 in |
Undercarriage
| Track Gauge | 104 in |
|---|---|
| Max Travel Speed | 1.8 mph |
| Shoe Size | 28 in |
| Number of Shoes per Side | 47 |
| Drawbar Pull | 52,790 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 288 in |
|---|---|
| Max Reach Along Ground | 424 in |
| Max Loading Height | 264 in |
| Max Vertical Wall Digging Depth | 180 in |
| Max Cutting Height | 371 in |
| Shipping Length of Unit | 434 in |
| Shipping Height of Unit | 143 in |
Boom/Stick Excavator Option 2
| Max Digging Depth | 312 in |
|---|---|
| Max Vertical Wall Digging Depth | 191 in |
| Max Cutting Height | 378 in |
| Max Loading Height | 272 in |
| Max Reach Along Ground | 445 in |
| Shipping Length of Unit | 433 in |
| Shipping Height of Unit | 148 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 324 in |
|---|---|
| Max Cutting Height | 349 in |
| Max Loading Height | 257 in |
| Max Vertical Wall Digging Depth | 126 in |
| Max Reach Along Ground | 448 in |
| Shipping Length of Unit | 433 in |
| Shipping Height of Unit | 139 in |
