Caterpillar
Kobelco
SK260LC-9
Excavator
63 specifications
1 / 5
Image 1 of 5
Specifications
59 data points
Operating Specifications
| Operating Weight (w/Deep Trencher) | 162,657 lb |
|---|---|
| Fuel Capacity | 180.2 gal |
| Hydraulic Pump Flow Capacity | 232.0 gal/min |
| Hydraulic System Fluid Capacity | 192.6 gal |
| Engine Oil Capacity | 12.3 gal |
| Cooling System Fluid Capacity | 20.5 gal |
| Operating Voltage | 24 V |
| Swing Speed | 5 rpm |
| Alternator Supplied Amperage (w/Deep Trencher) | 50 A |
| Hydraulic System Relief Valve Pressure (w/Deep Trencher) | 4,500 psi |
| Swing Drive Fluid Capacity (w/Deep Trencher) | 11.8 gal |
Engine
| Engine Model | 3406 |
|---|---|
| Displacement | 891 in³ |
| Power Measured @ | 2,100 rpm |
| Net Power | 360.0 hp |
| Engine Model (w/Deep Trencher) | 3406B |
| Aspiration (w/Deep Trencher) | turbocharged and aftercooled |
Dimensions
| Height - Top of Cab | 143 in |
|---|---|
| Width to Outside of Tracks | 143 in |
| Upper Structure Ground Clearance | 42 in |
| Length of Tracks | 222 in |
| Removal Counterweight Clearance (w/Deep Trencher) | 43 in |
| Tail Swing Radius (w/Deep Trencher) | 155 in |
| Ground Clearance (w/Deep Trencher) | 30 in |
Undercarriage
| Track Gauge | 128 in |
|---|---|
| Max Travel Speed | 2.0 mph |
| Loading Shovel Operating Weight | 146,122 lb |
| Loading Shovel Shoe Width | 24 in |
| Loading Shovel Ground Pressure | 16 psi |
| Backhoe Shoe Width 1 | 30 in |
| Backhoe Operating Weight - Shoe 1 | 143,631 lb |
| Backhoe Ground Pressure - Shoe 1 | 12 psi |
| Number of Track Shoes per Side | 45 |
| Backhoe Shoe Width 2 | 24 in |
| Backhoe Ground Pressure - Shoe 2 | 15 psi |
| Backhoe Shoe Width 3 | 36 in |
| Shoe Size (w/Deep Trencher) | 36 in |
| Track Gauge (w/Deep Trencher) | 113 in |
| Ground Pressure (w/Deep Trencher) (w/Deep Trencher) | 10 psi |
| Drawbar Pull (w/Deep Trencher) | 96,218 lb |
Swing Mechanism
| Swing Speed (w/Deep Trencher) | 5 rpm |
|---|
Loading Shovel
| Max Cutting Height | 406 in |
|---|---|
| Max Dump Height | 222 in |
| Max Dig Reach | 374 in |
Backhoe Boom / Stick 1
| Max Dig Depth | 307 in |
|---|---|
| Max Cutting Height | 454 in |
| Max Dump Height | 300 in |
| Max Reach on Ground | 490 in |
| Max Vertical Wall Dig Depth | 200 in |
Backhoe Boom / Stick 2
| Max Dig Depth | 331 in |
|---|---|
| Max Cutting Height | 448 in |
| Max Dump Height | 295 in |
| Max Reach on Ground | 505 in |
| Max Vertical Wall Dig Depth | 211 in |
Backhoe Boom / Stick 3
| Max Dig Depth | 378 in |
|---|---|
| Max Cutting Height | 462 in |
| Max Dump Height | 311 in |
| Max Reach on Ground | 550 in |
| Max Vertical Wall Dig Depth | 254 in |
