CaterpillarCaterpillar
570
Processor
18 specifications
1 / 5
Image 1 of 5
Specifications
17 data points
Operating Specifications
| Operating Weight | 34,017 lb |
|---|---|
| Fuel Capacity | 105.7 gal |
| Hydraulic System Fluid Capacity | 39.7 gal |
| Cooling System Fluid Capacity | 13.3 gal |
| Engine Oil Capacity | 8.0 gal |
Engine
| Engine Model | Cat C7 ACERT |
|---|---|
| Displacement | 439 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 197.0 hp |
| Net Power | 154.0 hp |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 555 lb-ft |
Dimensions
| Height - Top of Cab | 134 in |
|---|---|
| Overall Width | 110 in |
| Shipping Length - non tilt | 263 in |
Drive System
| Tire Size - front | 600/65-34 14PR |
|---|---|
| Tire Size - rear | 700/55-34 14PR |
