444E Loader w/ Coupler
Wheel Loader
45 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 32,408 lb |
|---|---|
| Fuel Capacity | 58.7 gal |
| Hydraulic System Fluid Capacity | 40.5 gal |
| Static Tipping Weight | 22,840 lb |
| Turning Radius | 271 in |
Engine
| Engine Model | 3304 |
|---|---|
| Displacement | 427 in³ |
| Net Power | 156.9 hp |
Hydraulic System
| Raise Time | 6.6 s |
|---|---|
| Lower Time | 3.0 s |
| Dump Time | 2.2 s |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 137 in |
| Wheelbase | 126 in |
| Width Over Tires | 106 in |
| Reach at Max Lift and Dump | 42 in |
| Length with Bucket on Ground | 285 in |
Transmission
| Max Speed - Forward | 22.7 mph |
|---|---|
| Max Speed - Reverse | 24.5 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 3.81 yd³ |
|---|---|
| Bucket Capacity - struck | 2.69 yd³ |
| Dump Clearance at Max Raise | 117 in |
| Bucket Width | 109 in |
