CaterpillarCaterpillar
928G
Wheel Loader
105 specifications
1 / 5
Image 1 of 5
Specifications
50 data points
Operating Specifications
| Operating Weight | 42,825 lb |
|---|---|
| Fuel Capacity | 83.0 gal |
| Hydraulic System Fluid Capacity | 50.0 gal |
| Static Tipping Weight | 24,269 lb |
| Breakout Force | 36,203 lb |
Engine
| Engine Model | Cat C7.1 ACERT |
|---|---|
| Displacement | 428 in³ |
| Stroke | 5 in |
| Bore | 4 in |
| Net Power - ISO 9249 | 211.0 hp |
| Peak Net Torque - 1,400 rpm - SAE J1349 | 729 lb-ft |
Weights
| Operating Weight | 42,811 lb |
|---|
Hydraulic System
| Raise Time | 5.9 s |
|---|---|
| Lower Time | 2.5 s |
| Dump Time | 1.8 s |
| Hydraulic Cycle Time - Total | 10.0 s |
| Hydraulic Cycle Time - Lower, Empty, Float Down | 2.5 s |
| Steering System - Pump Type | Piston |
| Implement System - Maximum Operating Pressure | 3,800 psi |
| Hydraulic Cycle Time - Dump, at Maximum Raise | 1.8 s |
| Hydraulic Cycle Time - Raise from Carry Position | 5.9 s |
Transmission
| Max Speed - Forward | 23.6 mph |
|---|---|
| Max Speed - Reverse | 24.8 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Forward - 1 | 4.3 mph |
| Reverse - 1 | 4.7 mph |
| Forward - 2 | 8.0 mph |
| Reverse - 2 | 8.8 mph |
| Forward - 3 | 14.1 mph |
| Reverse - 3 | 15.4 mph |
| Forward - 4 | 23.6 mph |
| Reverse - 4 | 24.7 mph |
Brakes & Steering
| Brakes | Meet OSHA SAE J1473 OCT90 and ISO 3450-1985 required standards |
|---|
Cab & Operator
| ROPS/FOPS | Meets SAE and ISO standards |
|---|
Tires & Wheels
| Tires | Choices |
|---|
Bucket
| Bucket Capacity - heaped | 15.70 yd³ |
|---|---|
| Breakout Force | 36,194 lb |
| Bucket Capacities | 3.24 – 11.99 yd³ |
Service Refill Capacities
| Cooling System | 15.9 gal |
|---|---|
| Transmission | 11.4 gal |
| Crankcase | 4.8 gal |
| Differential - Final Drives - Front | 11.4 gal |
| Differential - Final Drives - Rear | 11.4 gal |
| Hydraulic Tank | 49.9 gal |
| Fuel Tank - Standard | 83.0 gal |
Axles
| Front | Fixed |
|---|---|
| Rear | Oscillating ?13 degrees |
| Maximum Single-Wheel Rise and Fall | 19 in |
Sound
| Standards | Standards |
|---|
