Caterpillar
JCB
436ZX
Wheel Loader
39 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 36,900 lb |
|---|---|
| Fuel Capacity | 65.0 gal |
| Tire Size | 20.5-25 12 PR(L-3) |
| Hydraulic System Fluid Capacity | 52.1 gal |
| Static Tipping Weight | 28,153 lb |
Engine
| Engine Model | 3306 |
|---|---|
| Displacement | 641 in³ |
| Net Power | 170.0 hp |
Hydraulic System
| Raise Time | 6.2 s |
|---|---|
| Lower Time | 3.8 s |
| Dump Time | 1.6 s |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 141 in |
| Width Over Tires | 109 in |
| Reach at Max Lift and Dump | 31 in |
| Length with Bucket on Ground | 270 in |
| Hinge Pin - Max Height | 165 in |
Transmission
| Max Speed - Forward | 23.7 mph |
|---|---|
| Max Speed - Reverse | 28.1 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 4.09 yd³ |
|---|---|
| Dump Clearance at Max Raise | 117 in |
| Breakout Force | 25,578 lb |
| Bucket Width | 115 in |
