Doosan
Sumitomo
SH120-2
Excavator
54 specifications
1 / 5
Image 1 of 5
Specifications
52 data points
Operating Specifications
| Operating Weight | 45,856 lb |
|---|---|
| Fuel Capacity | 92.5 gal |
| Hydraulic Pump Flow Capacity | 122.5 gal/min |
| Hydraulic System Fluid Capacity | 74.0 gal |
| Hydraulic System Relief Valve Pressure | 4,699 psi |
| Engine Oil Capacity | 7.2 gal |
| Cooling System Fluid Capacity | 6.4 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 60 A |
| Tire Size | 10.0-20-14PR |
Engine
| Engine Model | DL06 |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 162.0 hp |
| Aspiration | turbocharged with air to air intercooler |
| Torque Measured @ | 1,400 rpm |
| Net Torque | 521 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 125 in |
| Wheelbase | 113 in |
| Overall Width | 8 in |
| Upper Structure Clearance | 50 in |
Transmission
| Max Travel Speed | 22.4 mph |
|---|---|
| Transmission Type | hydrostatic powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 238 in |
|---|---|
| Max Reach Along Ground | 383 in |
Bucket
| Reference Bucket Capacity | 0.99 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.50 yd³ |
| Minimum Bucket Capacity | 0.71 yd³ |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 207 in |
|---|---|
| Max Cutting Height | 372 in |
| Max Loading Height | 263 in |
| Shipping Length of Unit | 376 in |
| Shipping Height of Unit | 128 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 223 in |
|---|---|
| Max Cutting Height | 381 in |
| Max Loading Height | 272 in |
| Shipping Height of Unit | 126 in |
| Shipping Length of Unit | 373 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 238 in |
|---|---|
| Max Cutting Height | 386 in |
| Max Loading Height | 277 in |
| Shipping Height of Unit | 126 in |
| Shipping Length of Unit | 372 in |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 247 in |
|---|---|
| Max Cutting Height | 396 in |
| Max Loading Height | 285 in |
| Shipping Height of Unit | 138 in |
| Shipping Length of Unit | 371 in |
