SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
58 data points
Operating Specifications
| Operating Weight | 94,779 lb |
|---|---|
| Fuel Capacity | 169.1 gal |
| Hydraulic System Fluid Capacity | 126.9 gal |
| Engine Oil Capacity | 11.9 gal |
| Cooling System Fluid Capacity | 13.5 gal |
| Swing Drive Fluid Capacity | 2.2 gal |
| DEF tank capacity | 18.5 gal |
| Hydraulic Tank | 103.1 gal |
Engine
| Engine Model | DC09 |
|---|---|
| Displacement | 775 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 345.0 hp |
| Net Power | 338.0 hp |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 1,179 lb-ft |
| Engine Make | Scania |
| Bore | 5 in |
| Stroke | 6 in |
| Air cleaner | Double Elements |
| Starter | 8.0 hp |
Hydraulic System
| Pilotpump-Gear Design | 6.4 gal/min |
|---|---|
| Relief Pressure - Boost | 4,694 psi |
| Relief Pressure -Normal | 4,694 psi |
Dimensions
| Height - Top of Cab | 125 in |
|---|---|
| Length of Track on Ground | 204 in |
| Tail Swing Radius | 149 in |
| Counterweight Clearance | 49 in |
| Undercarriage Width | 141 in |
| Track Shoe Width | 378 in |
| Overall width -Upper Structure | 119 in |
Undercarriage
| Ground Pressure | 9 psi |
|---|---|
| Track Gauge | 109 in |
| Shoe Size | 32 in |
| Number of Shoes per Side | 50 |
| Number of bottom rollers per side | 9 |
| Number of top rollers per side | 2 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 305 in |
|---|---|
| Max Reach Along Ground | 444 in |
| Max Loading Height | 119 in |
| Max Vertical Wall Digging Depth | 170 in |
| Max Cutting Height | 426 in |
| Shipping Length of Unit | 463 in |
| Shipping Height of Unit | 122 in |
| Minimum swing radius | 176 in |
| Min Digging Reach | 454 in |
| Bucket Digging Force | 59,799 lb |
| Arm Digging Force | 43,388 lb |
Bucket
| Reference Bucket Capacity | 2.00 yd³ |
|---|
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Electrical System
| Alternator | — |
|---|---|
| Battery | 12 V 200 AH 1300 |
| Starter | 24 V |
Performance
| Maximum Grade | 70.0 % |
|---|---|
| Swing - Normal Mode | 4,694 psi |
| Swing-Power Mode | 4,978 psi |
| Traction Force -Draw bar Pull | 90,168 lb-ft |
| Travel-Normal Mode | 4,694 psi |
| Travel-Power Mode | 4,978 psi |
