Doosan
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 67,540 lb |
|---|---|
| Fuel Capacity | 118.9 gal |
| Hydraulic Pump Flow Capacity | 132.1 gal/min |
| Hydraulic System Fluid Capacity | 76.7 gal |
| Hydraulic System Relief Valve Pressure | 4,690 psi |
| Engine Oil Capacity | 6.4 gal |
| Cooling System Fluid Capacity | 9.8 gal |
| Swing Drive Fluid Capacity | 1.6 gal |
Engine
| Engine Model | DE08TIS |
|---|---|
| Displacement | 493 in³ |
| Power Measured @ | 1,900 rpm |
| Net Power | 197.0 hp |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 121 in |
| Length of Track on Ground | 158 in |
| Tail Swing Radius | 126 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 47 in |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Track Gauge | 103 in |
| Shoe Size | 24 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 546 in |
|---|---|
| Max Reach Along Ground | 683 in |
| Max Loading Height | 465 in |
| Max Vertical Wall Digging Depth | 497 in |
| Max Cutting Height | 556 in |
