Doosan
SOLAR 500LC-V
- Operating Weight
- 110,011 lb
- Max Digging Depth
- 248 in
- Max Digging Depth
- 268 in
- Net Power
- 311.2 hp
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Operating Weight | 110,011 lb |
|---|---|
| Fuel Capacity | 163.8 gal |
| Hydraulic Pump Flow Capacity | 189.7 gal/min |
| Hydraulic System Fluid Capacity | 70.1 gal |
| Hydraulic System Relief Valve Pressure | 4,550 psi |
| Engine Oil Capacity | 7.4 gal |
| Cooling System Fluid Capacity | 15.4 gal |
| Swing Drive Fluid Capacity | 1.1 gal |
Engine
| Engine Model | DE12TIS |
|---|---|
| Displacement | 674 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 311.2 hp |
Dimensions
| Ground Clearance | 30 in |
|---|---|
| Height - Top of Cab | 132 in |
| Length of Track on Ground | 176 in |
| Tail Swing Radius | 145 in |
| Width to Outside of Tracks | 154 in |
| Removal Counterweight Clearance | 49 in |
Undercarriage
| Ground Pressure | 12 psi |
|---|---|
| Track Gauge | 131 in |
| Shoe Size | 24 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 248 in |
|---|---|
| Max Reach Along Ground | 394 in |
| Max Loading Height | 260 in |
| Max Vertical Wall Digging Depth | 22 in |
| Max Cutting Height | 371 in |
| Shipping Length of Unit | 457 in |
| Shipping Height of Unit | 163 in |
Bucket
| Reference Bucket Capacity | 3.81 yd³ |
|---|---|
| Maximum Bucket Capacity | 4.80 yd³ |
| Minimum Bucket Capacity | 2.69 yd³ |
Boom/Stick Excavator Option 2
| Max Digging Depth | 268 in |
|---|---|
| Max Vertical Wall Digging Depth | 43 in |
| Max Cutting Height | 376 in |
| Max Loading Height | 264 in |
| Max Reach Along Ground | 411 in |
| Shipping Length of Unit | 449 in |
| Shipping Height of Unit | 168 in |
