Gehl
Dynapac
F5CS
Asphalt Paver
17 specifications
1 / 5
Image 1 of 5
Specifications
14 data points
Operating Specifications
| Operating Weight w/ Screed | 10,600 lb |
|---|---|
| Fuel Capacity | 12.5 gal |
| Hydraulic System Fluid Capacity | 20.0 gal |
Engine
| Power Measured @ | 3,000 rpm |
|---|---|
| Net Power | 48.0 hp |
| Make | Yanmar |
Dimensions
| Transport Width | 103 in |
|---|---|
| Transport Height | 86 in |
| Length w/ Screed | 115 in |
| Width w/ Hopper Open | 126 in |
Hopper/Paver
| Paving Width - max | 156 in |
|---|---|
| Paving Speed - max | 1.5 mph |
| Hopper Capacity | 6 lb |
| Paving Thickness - max | 1 in |
