Genie
Haulotte
COMPACT 2032E
Aerial Lift
26 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Engine
| System Voltage | 24 V |
|---|---|
| Battery Amp Hours | 245 |
| Number of Batteries | 4 |
Dimensions
| Ground Clearance | 3 in |
|---|---|
| Wheelbase | 53 in |
| Overall Length | 6 in |
| Overall Width | 32 in |
| Turning Radius | 65 in |
| Height w/ Rails | 80 in |
| Height w/o Rails | 69 in |
Performance
| Operating Weight | 2,729 lb |
|---|---|
| Max Speed | 2.5 mph |
| Tire Size | 12x4.5x8 |
| Tire Fill/Type | Solid non-marking |
Platform
| Max Platform Height | 181 in |
|---|---|
| Max Platform Weight Capacity | 600 lb |
| Platform Inner Length | 64 in |
| Platform Inner Width | 29 in |
| Max Working Height | 260 in |
| Lift Time | 16.0 s |
| Deck Extension | 36 in |
| Lower Time | 17.0 s |
