Genie
JLG
1350SJP
Aerial Lift
27 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Engine
| Engine Model | TD2011 L04i |
|---|---|
| Gross Power | 74.0 hp |
| Fuel Type | diesel |
Dimensions
| Ground Clearance | 2 in |
|---|---|
| Wheelbase | 145 in |
| Overall Length | 47 in |
| Overall Width | 98 in |
| Turning Radius | 267 in |
| Overall Height - mast lowered | 121 in |
Performance
| Operating Weight | 44,639 lb |
|---|---|
| Max Speed | 3.0 mph |
| Tire Size | 445/65D22.5 |
| Hydraulic System Fluid Capacity | 55.0 gal |
| Fuel Capacity | 39.9 gal |
Platform
| Max Platform Height | 1,502 in |
|---|---|
| Max Platform Weight Capacity | 500 lb |
| Platform Inner Length | 96 in |
| Platform Inner Width | 36 in |
| Max Working Height | 1,581 in |
| Max Horizontal Reach | 960 in |
| Platform Rotation | 160 ° |
