Hidromek
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
.jpg)
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 67,241 lb |
|---|---|
| Fuel Capacity | 127.6 gal |
| Hydraulic Pump Flow Capacity | 137.4 gal/min |
| Hydraulic System Fluid Capacity | 97.8 gal |
| Hydraulic System Relief Valve Pressure | 5,121 psi |
| Engine Oil Capacity | 7.4 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.6 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | 6D16-TLU2J |
|---|---|
| Displacement | 460 in³ |
| Power Measured @ | 2,150 rpm |
| Net Power | 216.0 hp |
| Aspiration | Turbocharger intercooler |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 630 lb-ft |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 124 in |
| Length of Track on Ground | 159 in |
| Tail Swing Radius | 127 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 47 in |
Undercarriage
| Track Gauge | 103 in |
|---|---|
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.1 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 51 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 56,989 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 268 in |
|---|---|
| Max Reach Along Ground | 401 in |
| Max Loading Height | 277 in |
| Max Vertical Wall Digging Depth | 234 in |
| Max Cutting Height | 397 in |
| Shipping Length of Unit | 425 in |
| Shipping Height of Unit | 141 in |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
