Hitachi
Hyundai
ROBEX 290LC-7 LR
Excavator
25 specifications
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Operating Weight | 120,593 lb |
|---|---|
| Fuel Capacity | 185.0 gal |
| Hydraulic Pump Flow Capacity | 100.9 gal/min |
| Hydraulic System Fluid Capacity | 148.0 gal |
| Engine Oil Capacity | 11.7 gal |
| Cooling System Fluid Capacity | 18.5 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 3.5 gal |
Engine
| Engine Model | NTA855 |
|---|---|
| Displacement | 854 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 394.3 hp |
| Net Power | 364.8 hp |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 1,136 lb-ft |
| Engine Make | Cummins |
| Stroke | 6 in |
| Bore | 6 in |
Dimensions
| Ground Clearance | 32 in |
|---|---|
| Height - Top of Cab | 138 in |
| Length of Track on Ground | 210 in |
| Tail Swing Radius | 150 in |
| Width to Outside of Tracks | 155 in |
| Removal Counterweight Clearance | 57 in |
Undercarriage
| Ground Pressure | 14 psi |
|---|---|
| Track Gauge | 126 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.0 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 49 |
| Number of Carrier Rollers per Side | 3 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 325 in |
|---|---|
| Max Reach Along Ground | 503 in |
| Max Loading Height | 329 in |
| Max Vertical Wall Digging Depth | 239 in |
| Max Cutting Height | 474 in |
| Shipping Length of Unit | 509 in |
| Shipping Height of Unit | 168 in |
Bucket
| Maximum Bucket Capacity | 4.50 yd³ |
|---|
Swing Mechanism
| Swing Speed | 8 rpm |
|---|
