Hitachi
John Deere
210G LC
Excavator
36 specifications
1 / 5
Image 1 of 5
Specifications
43 data points
Operating Specifications
| Operating Weight | 26,674 lb |
|---|---|
| Fuel Capacity | 75.3 gal |
| Hydraulic Pump Flow Capacity | 18.3 gal/min |
| Hydraulic System Relief Valve Pressure | 27 psi |
| Engine Oil Capacity | 4.5 gal |
| Cooling System Fluid Capacity | 5.6 gal |
Engine
| Engine Model | 4JJ1 |
|---|---|
| Displacement | 183 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 101.0 hp |
| Aspiration | Turbocharged and charged air cooled |
| Alternator | 50 A |
| Emission Tier Level | EPA Final Tier 4 |
| Battery | 2 |
| Off-Level Capacity | 70.0 % |
Hydraulic System
| Implement - Operating Pressure | 4,980 psi |
|---|---|
| Travel - Operating Pressure | 4,980 psi |
| Controls | Pilot levers short-stroke low-effort hydraulic pilot controls with shutoff lever |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Tail Swing Radius | 86 in |
| Overall Height | 108 in |
| Track Gauge | 79 in |
| Counterweight Clearance | 33 in |
| Undercarriage Overall Length | 143 in |
| Cab height | 11 in |
| Center to center - idler to sprocket | 114 in |
Undercarriage
| Number of Track Rollers per Side | 7 |
|---|---|
| Number of Carrier Rollers per Side | 1 |
| Drawbar Pull | 24,729 lb |
| Track Adjustment | Hydraulic |
Boom/Stick Excavator Option 1
| Max Digging Depth | 220 in |
|---|---|
| Max Reach Along Ground | 315 in |
| Max Vertical Wall Digging Depth | 199 in |
| Max Cutting Height | 340 in |
| Max.Dumping Height | 245 in |
| Bucket Digging Force - SAE | 20,525 lb |
| Bucket Digging Force - ISO | 23,435 lb |
| Arm Digging Force - ISO | 15,476 lb |
| Arm Digging Force - SAE | 14,991 lb |
Swing Mechanism
| Swing Speed | 13 rpm |
|---|
Boom/Stick Excavator Option 3
| Overall height | 108 in |
|---|
Performance
| Travel speed low | 2.1 mph |
|---|---|
| Travel Speed - High | 3.5 mph |
