Hitachi
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 83,370 lb |
|---|---|
| Fuel Capacity | 269.0 gal |
| Hydraulic Pump Flow Capacity | 115.8 gal/min |
| Cooling System Fluid Capacity | 6.3 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 2.1 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | CC-6BG1T |
|---|---|
| Displacement | 396 in³ |
| Power Measured @ | 2,150 rpm |
| Gross Power | 173.0 hp |
| Net Power | 165.0 hp |
| Engine Make | Isuzu |
Dimensions
| Ground Clearance | 29 in |
|---|---|
| Height - Top of Cab | 146 in |
| Length of Track on Ground | 199 in |
| Tail Swing Radius | 130 in |
Undercarriage
| Ground Pressure | 10 psi |
|---|---|
| Shoe Size | 28 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 205 in |
|---|---|
| Max Reach Along Ground | 480 in |
| Max Cutting Height | 558 in |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
