Hitachi
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
Hitachi
ZX345USLC-6
- Operating Weight
- 76,500 lb
- Max Digging Depth
- 274 in
- Max Digging Depth
- 299 in
- Net Power
- 249.0 hp
1 / 5
Image 1 of 5
Specifications
66 data points
Operating Specifications
| Operating Weight | 76,500 lb |
|---|
Engine
| Engine Model | 6HK1 |
|---|---|
| Displacement | 476 in³ |
| Power Measured @ | 1,900 rpm |
| Net Power | 249.0 hp |
| Aspiration | Turbocharged and charged air cooled |
| Engine Make | Isuzu |
| Emissions level | EPA Final Tier 4 / EU Stage IV |
| Off-Level Capacity | 70.0 % |
Hydraulic System
| Main pump - Maximum flow | 62.4 gal |
|---|---|
| Hydraulic System Type | Open center load sensing |
| Implement - Operating Pressure | 5,033 psi |
| Travel - Operating Pressure | 5,149 psi |
| Controls | Pilot levers |
| Main pump type | 3 variable-displacement axial-piston pumps |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Counterweight Clearance | 47 in |
| Undercarriage Overall Length | 196 in |
| Cab height | 127 in |
Undercarriage
| Number of Track Rollers per Side | 8 |
|---|---|
| Max Travel Speed | 2.6 mph |
| Number of Shoes per Side | 49 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 66,990 lb |
Fluid Capacities
| Fuel Tank | 100.4 gal |
|---|---|
| Hydraulic system | 87.2 gal |
| Cooling system | 10.9 gal |
| Hydraulic Tank | 42.3 gal |
| Engine oil with filter | 12.7 gal |
| Swing drive | 3.1 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 274 in |
|---|---|
| Max Reach Along Ground | 356 in |
| Max Vertical Wall Digging Depth | 243 in |
| Max Cutting Height | 44,922 in |
| Max Digging Reach | 43 in |
| Max.Dumping Height | 330 in |
| Bucket Digging Force - SAE | 39,342 lb |
| Bucket Digging Force - ISO | 45,412 lb |
| Arm Digging Force - ISO | 32,373 lb |
| Arm Digging Force - SAE | 31,024 lb |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 299 in |
|---|---|
| Max Vertical Wall Digging Depth | 265 in |
| Max Cutting Height | 461 in |
| Max Reach Along Ground | 379 in |
| Minimum swing radius | 134 in |
| Max Digging Reach | 451 in |
| Max.Dumping Height | 342 in |
| Bucket Digging Force - SAE | 39,342 lb |
| Bucket Digging Force - ISO | 45,412 lb |
| Arm Digging Force - SAE | 27,202 lb |
| Arm Digging Force - ISO | 28,551 lb |
Electrical System
| Batteries | 2 volts |
|---|---|
| Voltage | — |
| Battery capacity | — |
| Alternator rating | 50 amp |
| Work Lights | 5halogen |
Cylinders
| Bore (Boom) | 5 in |
|---|---|
| Bore (Bucket) | 42 in |
| Stroke (Bucket) | 3 in |
| Bore (Arm) | 5 in |
| Stroke (Arm) | 58 in |
| Stroke (Boom) | 50 in |
| Rod Diameter (Arm) | 4 in |
| Rod Diameter (Boom) | 3 in |
| Rod Diameter (Bucket) | 3 in |
