Hitachi
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 75,398 lb |
|---|---|
| Fuel Capacity | 166.5 gal |
| Hydraulic Pump Flow Capacity | 152.2 gal/min |
| Hydraulic System Fluid Capacity | 98.9 gal |
| Engine Oil Capacity | 10.9 gal |
| Cooling System Fluid Capacity | 8.5 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 4.5 gal |
Engine
| Engine Model | AH-6HK1X |
|---|---|
| Power Measured @ | 1,900 rpm |
| Net Power | 270.9 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 797 lb-ft |
| Engine Make | Isuzu |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 125 in |
| Length of Track on Ground | 196 in |
| Tail Swing Radius | 134 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 47 in |
Undercarriage
| Ground Pressure | 9 psi |
|---|---|
| Track Gauge | 102 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.2 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 48 |
| Number of Carrier Rollers per Side | 2 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 292 in |
|---|---|
| Max Reach Along Ground | 430 in |
| Max Loading Height | 285 in |
| Max Vertical Wall Digging Depth | 253 in |
| Max Cutting Height | 408 in |
| Shipping Length of Unit | 433 in |
| Shipping Height of Unit | 130 in |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
