Hitachi
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 85,319 lb |
|---|---|
| Fuel Capacity | 166.5 gal |
| Hydraulic Pump Flow Capacity | 152.2 gal/min |
| Hydraulic System Fluid Capacity | 98.9 gal |
| Hydraulic System Relief Valve Pressure | 4,975 psi |
| Engine Oil Capacity | 10.9 gal |
| Cooling System Fluid Capacity | 8.5 gal |
| Swing Drive Fluid Capacity | 4.5 gal |
Engine
| Engine Model | AH-6HK1X |
|---|---|
| Displacement | 475 in³ |
| Power Measured @ | 1,900 rpm |
| Net Power | 270.9 hp |
| Aspiration | Turbochargedintercooled |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 797 lb-ft |
Dimensions
| Ground Clearance | 23 in |
|---|---|
| Height - Top of Cab | 134 in |
| Length of Track on Ground | 148 in |
| Tail Swing Radius | 134 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 50 in |
Undercarriage
| Ground Pressure | 11 psi |
|---|---|
| Track Gauge | 102 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.2 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 46 |
| Number of Carrier Rollers per Side | 2 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 288 in |
|---|---|
| Max Reach Along Ground | 428 in |
| Max Loading Height | 284 in |
| Max Vertical Wall Digging Depth | 263 in |
| Max Cutting Height | 407 in |
| Shipping Length of Unit | 434 in |
| Shipping Height of Unit | 134 in |
Bucket
| Reference Bucket Capacity | 2.00 yd³ |
|---|
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
