Hitachi

ZX480MT

Excavator

Operating Weight
104,279 lb
Max Digging Depth
233 in
Max Digging Depth
246 in
Net Power
314.0 hp
All excavators
Hitachi ZX480MT Excavator
1 / 5
Image 1 of 5
Image: soonparts.com

Specifications

68 data points

Operating Specifications

Operating Specifications specifications
Operating Weight104,279 lb
Fuel Capacity191.6 gal
Hydraulic Pump Flow Capacity190.3 gal/min
Hydraulic System Fluid Capacity148.0 gal
Hydraulic System Relief Valve Pressure4,975 psi
Engine Oil Capacity15.1 gal
Cooling System Fluid Capacity14.6 gal
Operating Voltage12 V
Swing Drive Fluid Capacity1.8 gal

Engine

Engine specifications
Engine ModelAH-6WG1XYSA-01
Displacement957 in³
Power Measured @1,800 rpm
Net Power314.0 hp
AspirationTurbocharged
Torque Measured @1,500 rpm
Max Torque940 lb-ft

Dimensions

Dimensions specifications
Ground Clearance32 in
Height - Top of Cab137 in
Length of Track on Ground168 in
Tail Swing Radius138 in
Width to Outside of Tracks139 in
Removal Counterweight Clearance56 in

Undercarriage

Undercarriage specifications
Ground Pressure12 psi
Track Gauge115 in
Number of Track Rollers per Side8
Max Travel Speed2.5 mph
Shoe Size24 in
Number of Shoes per Side49
Number of Carrier Rollers per Side3

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth233 in
Max Reach Along Ground407 in
Max Loading Height284 in
Max Vertical Wall Digging Depth182 in
Max Cutting Height424 in
Shipping Length of Unit466 in
Shipping Height of Unit138 in

Bucket

Bucket specifications
Maximum Bucket Capacity3.51 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed9 rpm

Boom/Stick Excavator Option 2

Boom/Stick Excavator Option 2 specifications
Max Digging Depth246 in
Max Vertical Wall Digging Depth198 in
Max Cutting Height428 in
Max Loading Height289 in
Max Reach Along Ground419 in

Boom/Stick Excavator Option 3

Boom/Stick Excavator Option 3 specifications
Max Digging Depth287 in
Max Cutting Height441 in
Max Loading Height277 in
Max Vertical Wall Digging Depth207 in
Max Reach Along Ground441 in
Shipping Length of Unit466 in
Shipping Height of Unit138 in

Boom/Stick Excavator Option 4

Boom/Stick Excavator Option 4 specifications
Max Digging Depth306 in
Max Cutting Height435 in
Max Reach Along Ground467 in
Max Loading Height301 in
Max Vertical Wall Dig Depth260 in
Shipping Length of Unit466 in

Boom/Stick Excavator Option 5

Boom/Stick Excavator Option 5 specifications
Max Digging Depth326 in
Max Reach Along Ground483 in
Max Cutting Height441 in
Max Loading Height306 in
Max Vertical Wall Dig Depth276 in
Shipping Height of Unit138 in

Boom/Stick Excavator Option 6

Boom/Stick Excavator Option 6 specifications
Max Digging Depth359 in
Max Reach Along Ground519 in
Max Cutting Height462 in
Max Loading Height342 in
Max Vertical Wall Dig Depth332 in
Shipping Length of Unit466 in
