Hitachi

ZX600

Excavator

Operating Weight
129,191 lb
Max Digging Depth
280 in
Max Digging Depth
311 in
Net Power
395.0 hp
All excavators
Hitachi ZX600 Excavator
1 / 5
Image 1 of 5
Image: machinerytrader.com

Specifications

60 data points

Operating Specifications

Operating Specifications specifications
Operating Weight129,191 lb
Fuel Capacity195.5 gal
Hydraulic Pump Flow Capacity230.0 gal/min
Hydraulic System Fluid Capacity163.3 gal
Engine Oil Capacity14.6 gal
Cooling System Fluid Capacity25.9 gal
Operating Voltage24 V
Swing Drive Fluid Capacity2.8 gal

Engine

Engine specifications
Engine ModelBB-6WG1X
Displacement957 in³
Power Measured @1,800 rpm
Net Power395.0 hp
AspirationTurbocharged
Torque Measured @1,500 rpm
Max Torque1,140 lb-ft
Engine MakeIsuzu

Dimensions

Dimensions specifications
Ground Clearance32 in
Height - Top of Cab138 in
Length of Track on Ground210 in
Tail Swing Radius150 in
Width to Outside of Tracks150 in
Removal Counterweight Clearance57 in

Undercarriage

Undercarriage specifications
Ground Pressure9 psi
Track Gauge126 in
Number of Track Rollers per Side9
Max Travel Speed3.1 mph
Number of Shoes per Side51
Number of Carrier Rollers per Side3

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth280 in
Max Reach Along Ground455 in
Max Loading Height276 in
Max Vertical Wall Digging Depth203 in
Max Cutting Height425 in

Bucket

Bucket specifications
Maximum Bucket Capacity4.60 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed7 rpm

Boom/Stick Excavator Option 2

Boom/Stick Excavator Option 2 specifications
Max Digging Depth311 in
Max Vertical Wall Digging Depth267 in
Max Cutting Height457 in
Max Loading Height306 in
Max Reach Along Ground494 in

Boom/Stick Excavator Option 3

Boom/Stick Excavator Option 3 specifications
Max Digging Depth335 in
Max Cutting Height468 in
Max Loading Height316 in
Max Vertical Wall Digging Depth300 in
Max Reach Along Ground516 in

Boom/Stick Excavator Option 4

Boom/Stick Excavator Option 4 specifications
Max Digging Depth359 in
Max Cutting Height474 in
Max Reach Along Ground536 in
Max Loading Height322 in
Max Vertical Wall Dig Depth320 in

Boom/Stick Excavator Option 5

Boom/Stick Excavator Option 5 specifications
Max Digging Depth395 in
Max Reach Along Ground571 in
Max Cutting Height485 in
Max Loading Height348 in
Max Vertical Wall Dig Depth350 in

Boom/Stick Excavator Option 6

Boom/Stick Excavator Option 6 specifications
Max Digging Depth451 in
Max Reach Along Ground636 in
Max Cutting Height526 in
Max Loading Height389 in
Max Vertical Wall Dig Depth403 in
