Hitachi
ZX850H
- Operating Weight
- 167,331 lb
- Max Digging Depth
- 285 in
- Max Digging Depth
- 307 in
- Net Power
- 454.0 hp
1 / 5
Image 1 of 5
Specifications
54 data points
Operating Specifications
| Operating Weight | 167,331 lb |
|---|---|
| Fuel Capacity | 238.1 gal |
| Hydraulic Pump Flow Capacity | 8.0 gal/min |
| Hydraulic System Fluid Capacity | 177.0 gal |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
| Engine Oil Capacity | 14.6 gal |
| Cooling System Fluid Capacity | 28.3 gal |
| Operating Voltage | 12 V |
| Swing Drive Fluid Capacity | 4.0 gal |
Engine
| Engine Model | BB-6WG1T |
|---|---|
| Displacement | 957 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 454.0 hp |
| Aspiration | turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 1,374 lb-ft |
Dimensions
| Ground Clearance | 35 in |
|---|---|
| Height - Top of Cab | 144 in |
| Length of Track on Ground | 202 in |
| Tail Swing Radius | 170 in |
| Width to Outside of Tracks | 173 in |
| Removal Counterweight Clearance | 64 in |
Undercarriage
| Ground Pressure | 15 psi |
|---|---|
| Track Gauge | 137 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 2.7 mph |
| Shoe Size | 26 in |
| Number of Shoes per Side | 51 |
| Number of Carrier Rollers per Side | 3 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 285 in |
|---|---|
| Max Reach Along Ground | 490 in |
| Max Loading Height | 308 in |
| Max Vertical Wall Digging Depth | 172 in |
| Max Cutting Height | 461 in |
| Shipping Length of Unit | 564 in |
| Shipping Height of Unit | 182 in |
Bucket
| Reference Bucket Capacity | 4.50 yd³ |
|---|---|
| Maximum Bucket Capacity | 5.00 yd³ |
| Minimum Bucket Capacity | 1.80 yd³ |
Swing Mechanism
| Swing Speed | 8 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 307 in |
|---|---|
| Max Vertical Wall Digging Depth | 223 in |
| Max Cutting Height | 462 in |
| Max Loading Height | 309 in |
| Max Reach Along Ground | 504 in |
| Shipping Length of Unit | 564 in |
| Shipping Height of Unit | 182 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 349 in |
|---|---|
| Max Cutting Height | 473 in |
| Max Loading Height | 326 in |
| Max Vertical Wall Digging Depth | 238 in |
| Max Reach Along Ground | 545 in |
| Shipping Length of Unit | 564 in |
| Shipping Height of Unit | 182 in |
