Hitachi
Kobelco
SK260LC-9
Excavator
63 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 187,569 lb |
|---|---|
| Fuel Capacity | 293.3 gal |
| Hydraulic Fluid Capacity | 132.1 gal |
Engine
| Displacement | 957 in³ |
|---|---|
| Power Measured @ | 1,800 rpm |
| Net Power | 512.0 hp |
| Emissions level | Tier 4 |
Dimensions
| Ground Clearance | 36 in |
|---|---|
| Height - Top of Cab | 205 in |
| Length of Track on Ground | 202 in |
| Tail Swing Radius | 179 in |
Undercarriage
| Ground Pressure | 12 psi |
|---|---|
| Number of Track Rollers per Side | 8 |
| Shoe Size | 36 in |
| Number of Carrier Rollers per Side | 3 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 282 in |
|---|---|
| Max Reach Along Ground | 474 in |
| Shipping Length of Unit | 534 in |
| Shipping Height of Unit | 205 in |
| Max.Dumping Height | 320 in |
| Max Digging Height | 474 in |
