Hyundai
New Holland
E200SR
Excavator
44 specifications
1 / 5
Image 1 of 5
Specifications
62 data points
Operating Specifications
| Operating Weight | 36,156 lb |
|---|---|
| Fuel Capacity | 66.1 gal |
| Hydraulic Pump Flow Capacity | 87.2 gal/min |
| Hydraulic System Fluid Capacity | 63.5 gal |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
| Engine Oil Capacity | 6.4 gal |
| Cooling System Fluid Capacity | 9.3 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 50 A |
| Hydraulic Pump Type | two variable displacement piston pumps |
| Tire Size | 10-20-14PR dual type |
| Front Diff Fluid Capacity | 3.7 gal |
| Rear Diff Fluid Capacity | 3.7 gal |
Engine
| Engine Model | B5.9-C |
|---|---|
| Displacement | 359 in³ |
| Gross Power | 126.0 hp |
| Net Power | 116.0 hp |
| Aspiration | turbocharged |
| Net Torque | 390 lb-ft |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 122 in |
| Wheelbase | 103 in |
| Overall Width | 8 in |
| Tail Swing Radius | 101 in |
| Upper Structure Clearance | 50 in |
| Overall Width - Outriggers Down | 145 in |
Transmission
| Max Travel Speed | 18.7 mph |
|---|---|
| Transmission Type | 4-wheel hydrostatic drive |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Reference Bucket Capacity | 0.99 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.40 yd³ |
| Minimum Bucket Capacity | 0.60 yd³ |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 206 in |
|---|---|
| Max Cutting Height | 340 in |
| Max Reach Along Ground | 324 in |
| Max Loading Height | 238 in |
| Shipping Length of Unit | 347 in |
| Shipping Height of Unit | 125 in |
| Max Vertical Wall Dig Depth | 173 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 221 in |
|---|---|
| Max Cutting Height | 348 in |
| Max Reach Along Ground | 337 in |
| Max Loading Height | 246 in |
| Shipping Height of Unit | 121 in |
| Shipping Length of Unit | 343 in |
| Max Vertical Wall Dig Depth | 193 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 236 in |
|---|---|
| Max Cutting Height | 354 in |
| Max Reach Along Ground | 350 in |
| Max Loading Height | 252 in |
| Shipping Height of Unit | 120 in |
| Shipping Length of Unit | 349 in |
| Max Vertical Wall Dig Depth | 204 in |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 260 in |
|---|---|
| Max Cutting Height | 371 in |
| Max Reach Along Ground | 376 in |
| Max Loading Height | 267 in |
| Shipping Height of Unit | 135 in |
| Shipping Length of Unit | 348 in |
| Max Vertical Wall Dig Depth | 241 in |
