Hyundai
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
Hyundai
ROBEX 300LC-9A H/W
- Operating Weight
- 71,959 lb
- Max Digging Depth
- 243 in
- Max Digging Depth
- 258 in
- Net Power
- 225.0 hp
1 / 5
Image 1 of 5
Specifications
58 data points
Operating Specifications
| Operating Weight | 71,959 lb |
|---|---|
| Fuel Capacity | 132.1 gal |
| Hydraulic Pump Flow Capacity | 70.3 gal/min |
| Hydraulic System Fluid Capacity | 87.2 gal |
| Engine Oil Capacity | 6.4 gal |
| Cooling System Fluid Capacity | 10.6 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.6 gal |
| Alternator Supplied Amperage | 95 A |
Engine
| Engine Model | QSB6.7 |
|---|---|
| Displacement | 408 in³ |
| Power Measured @ | 1,900 rpm |
| Net Power | 225.0 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 700 lb-ft |
| Engine Make | Cummins |
Dimensions
| Ground Clearance | 31 in |
|---|---|
| Height - Top of Cab | 133 in |
| Length of Track on Ground | 196 in |
| Tail Swing Radius | 126 in |
| Width to Outside of Tracks | 137 in |
| Removal Counterweight Clearance | 60 in |
Undercarriage
| Ground Pressure | 9 psi |
|---|---|
| Track Gauge | 95 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.4 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 48 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 60,200 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 243 in |
|---|---|
| Max Reach Along Ground | 384 in |
| Max Loading Height | 285 in |
| Max Vertical Wall Digging Depth | 226 in |
| Max Cutting Height | 409 in |
| Shipping Length of Unit | 421 in |
| Shipping Height of Unit | 148 in |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 258 in |
|---|---|
| Max Vertical Wall Digging Depth | 220 in |
| Max Cutting Height | 403 in |
| Max Loading Height | 283 in |
| Max Reach Along Ground | 395 in |
| Shipping Length of Unit | 419 in |
| Shipping Height of Unit | 142 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 280 in |
|---|---|
| Max Cutting Height | 411 in |
| Max Loading Height | 292 in |
| Max Vertical Wall Digging Depth | 240 in |
| Max Reach Along Ground | 415 in |
| Shipping Length of Unit | 411 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 307 in |
|---|---|
| Max Cutting Height | 420 in |
| Max Reach Along Ground | 441 in |
| Max Loading Height | 300 in |
| Max Vertical Wall Dig Depth | 268 in |
| Shipping Length of Unit | 415 in |
