Hyundai

ROBEX 305LC-7

Excavator

Operating Weight
64,816 lb
Max Digging Depth
296 in
Net Power
255.0 hp
All excavators
Hyundai ROBEX 305LC-7 Excavator
1 / 5
Image 1 of 5
Image: machineryline.ng

Specifications

28 data points

Operating Specifications

Operating Specifications specifications
Operating Weight64,816 lb
Fuel Capacity126.9 gal
Hydraulic Pump Flow Capacity137.4 gal/min
Hydraulic System Fluid Capacity55.5 gal
Hydraulic System Relief Valve Pressure5,120 psi

Engine

Engine specifications
Engine ModelC8.3-C
Power Measured @1,900 rpm
Net Power255.0 hp
Torque Measured @1,500 rpm
Max Torque743 lb-ft

Dimensions

Dimensions specifications
Ground Clearance20 in
Height - Top of Cab119 in
Length of Track on Ground159 in
Tail Swing Radius126 in
Width to Outside of Tracks126 in
Removal Counterweight Clearance48 in

Undercarriage

Undercarriage specifications
Track Gauge103 in
Max Travel Speed3.3 mph
Shoe Size24 in
Drawbar Pull54,600 lb

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth296 in
Max Reach Along Ground426 in
Max Loading Height281 in
Max Cutting Height401 in
Shipping Length of Unit417 in
Shipping Height of Unit130 in

Bucket

Bucket specifications
Reference Bucket Capacity1.90 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed11 rpm
