EX70
Excavator
39 specifications
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Operating Weight | 12,015 lb |
|---|---|
| Fuel Capacity | 31.8 gal |
| Hydraulic Pump Flow Capacity | 31.8 gal/min |
| Hydraulic System Fluid Capacity | 18.5 gal |
| Hydraulic System Relief Valve Pressure | 3,130 psi |
| Engine Oil Capacity | 2.5 gal |
| Cooling System Fluid Capacity | 2.7 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 55 A |
| Hydraulic Pump Type | two variable displacement piston pumps |
| Tire Size | 12.0x16.5-12PR |
| Front Diff Fluid Capacity | 1.6 gal |
| Rear Diff Fluid Capacity | 1.3 gal |
Engine
| Engine Model | 4TNV94L |
|---|---|
| Displacement | 186 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 57.0 hp |
| Net Power | 55.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,440 rpm |
| Net Torque | 149 lb-ft |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 113 in |
| Wheelbase | 83 in |
| Overall Width | 6 in |
| Tail Swing Radius | 66 in |
| Upper Structure Clearance | 40 in |
Transmission
| Max Travel Speed | 16.8 mph |
|---|---|
| Transmission Type | 4-wheel hydrastatic drive mesh helical gear transmission |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Reference Bucket Capacity | 0.30 yd³ |
|---|
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 138 in |
|---|---|
| Max Cutting Height | 240 in |
| Max Reach Along Ground | 243 in |
| Max Loading Height | 172 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 150 in |
|---|---|
| Max Cutting Height | 247 in |
| Max Reach Along Ground | 253 in |
| Max Loading Height | 179 in |
