JCB
John Deere
302A
Backhoe Loader
42 specifications
1 / 5
Image 1 of 5
Specifications
73 data points
Operating Specifications
| Operating Weight 4wd | 6,150 lb |
|---|---|
| Operating Weight | 6,150 lb |
| Fuel Capacity | 11.9 gal |
| Hydraulic System Fluid Capacity | 11.9 gal |
| Cooling System Fluid Capacity | 2.2 gal |
| Tire Size Front - 2wd / 4wd | 7x15 |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 1.4 gal |
Engine
| Engine Model | 104-22 |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 50.0 hp |
| Net Power | 47.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Natural |
| Torque Measured @ | 2,000 rpm |
| Fuel Type | Replaceable cartridge plus water/sediment separator prefilter |
| Emissions Certification | Stage EC Stage IIIA |
| Net Max Torque | 100 lb-ft |
| Rated Engine Speed | 2,800 rpm |
Hydraulic System
| Pump Flow Capacity | 11.9 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Wheelbase | 43 in |
| Transport Width | 56 in |
| Transport Length | 131 in |
| Height to Top of Suspended Cab | 89 in |
Transmission
| Max Speed | 6.9 mph |
|---|---|
| Max Speed - Reverse | 6.9 mph |
| Number of Forward Gears | 1 |
| Number of Reverse Gears | 1 |
| Transmission Type | Hydrostatic |
Fluid Capacities
| Fuel Tank | 11.9 gal |
|---|---|
| Cooling system | 2.2 gal |
| Engine oil with filter | 2.6 gal |
Tires & Wheels
| Rear Tires Size | 7x15 |
|---|
General Specifications
| Operating Weight lbs (kg) | 6,150 (2,790) — Starting 2007 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 8.3 (2.55) — Starting 2013 Model Year |
| Lift Capacity lbs (kgs) | 1,345 (610) — Starting 2007 Model Year |
| Loading Height ft (m) | 7.66 (2.4) — Starting 2008 Model Year |
| 4th Gear Fwd mph (kmh) | hydrostatic — Starting 2007 Model Year |
| Backhoe Loading Height ft. (m) | 8.2 (2.5) — Starting 2011 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | 7 (11.3) — Starting 2013 Model Year |
| Breakout Force lbs (kgs) | 5,179 (2,350) — Starting 2007 Model Year |
| Digging Depth ft (m) | 8.33 (2.5) — Starting 2008 Model Year |
| Loader SAE HP (kw) | 50 (37) — Starting 2009 Model Year |
| Loader Lift Capacity lbs. (kg) | 1,345 (610) — Starting 2009 Model Year |
| Loader Breakout Force lbs. (kg) | 5,179 (2,350) — Starting 2009 Model Year |
| SAE Net hp (kW) | 47 (35) — Starting 2007 Model Year |
| SAE HP (KW) | 50 (37) — Starting 2010 Model Year |
| Weight lbs (kg) | 6,159 (2,790) — Starting 2010 Model Year |
Backhoe
| Max Digging Depth | 101 in |
|---|---|
| Max dig depth | 101 in |
| Dig Depth | 101 in |
| Reach From Swivel | 133 in |
| Loading Height | 94 in |
Loader
| Lift Capacity | 1,345 lb |
|---|---|
| Clearance at Max Dump Height | 83 in |
| Bucket Breakout Force | 5,179 lb |
| Bucket Width | 56 in |
| Reach at Max Dump Height | 12 in |
| Dig Depth | 2 in |
| SAE - Net | 47.0 hp |
| Breakout Force | — |
| Dump height | 83 in |
| Load over height | 100 in |
Travel Speed
| 4th Gear Fwd | 7.0 mph |
|---|
Electrical System
| Alternator | 50 |
|---|---|
| Battery | 72A/hour |
| Front working lights | 2 adjustable |
| Gauges | Fuel Level Hour meter |
| Pre-wire | Beacon |
| Rear working lights | 2 adjustable |
