21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
45 data points
Operating Specifications
| Fuel Capacity | 33.1 gal |
|---|---|
| Tire Size | 15.5x25x12 SGL |
| Hydraulic System Fluid Capacity | 29.1 gal |
| Static Tipping Weight | 11,835 lb |
| Operating Voltage | 12 V |
| Turning Radius | 203 in |
| Engine Oil Fluid Capacity | 2.7 gal |
| Rear Axle Oscillation | 25 ° |
| Alternator Supplied Amperage | 72 A |
| Front Axle/Diff Fluid Capacity | 6.7 gal |
| Rear Axle/Diff Fluid Capacity | 6.7 gal |
| Cooling System Fluid Capacity | 5.7 gal |
| Transmission Fluid Capacity | 4.8 gal |
Engine
| Engine Model | 1004-4TLR2 |
|---|---|
| Displacement | 244 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 90.0 hp |
| Net Power | 80.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 240 lb-ft |
Hydraulic System
| Pump Flow Capacity | 13.4 gal/min |
|---|---|
| Raise Time | 4.6 s |
| Lower Time | 3.0 s |
| Dump Time | 1.4 s |
| Relief Valve Setting | 3,190 psi |
| Pump Type | double gear pump with automatic unloader |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 119 in |
| Wheelbase | 107 in |
| Width Over Tires | 88 in |
| Reach at Max Lift and Dump | 37 in |
| Length with Bucket on Ground | 235 in |
| Hinge Pin - Max Height | 138 in |
Transmission
| Max Speed - Forward | 24.3 mph |
|---|---|
| Max Speed - Reverse | 16.2 mph |
| Transmission Type | semi automatic full powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 1.60 yd³ |
|---|---|
| Bucket Capacity - struck | 1.40 yd³ |
| Dump Clearance at Max Raise | 104 in |
| Breakout Force | 16,456 lb |
| Bucket Width | 89 in |
