JCB

JS330LC

Excavator

Operating Weight
70,744 lb
Max Digging Depth
247 in
Max Digging Depth
264 in
Net Power
271.0 hp
All excavators
JCB JS330LC Excavator
1 / 5
Image 1 of 5
Image: veritread.com

Specifications

71 data points

Operating Specifications

Operating Specifications specifications
Operating Weight70,744 lb
Fuel Capacity136.9 gal
Hydraulic Pump Flow Capacity153.3 gal/min
Hydraulic System Fluid Capacity84.6 gal
Hydraulic System Relief Valve Pressure4,627 psi
Engine Oil Capacity10.1 gal
Cooling System Fluid Capacity10.1 gal
Operating Voltage24 V
Swing Drive Fluid Capacity3.9 gal
Alternator Supplied Amperage50 A

Engine

Engine specifications
Engine ModelAH-6HKIX
Displacement475 in³
Power Measured @2,000 rpm
Gross Power281.0 hp
Net Power271.0 hp
AspirationTurbocharged and intercooled
Max Digging Reach435 in

Dimensions

Dimensions specifications
Ground Clearance20 in
Height - Top of Cab126 in
Length of Track on Ground157 in
Tail Swing Radius142 in
Width to Outside of Tracks126 in
Removal Counterweight Clearance48 in
Undercarriage Overall Length192 in

Undercarriage

Undercarriage specifications
Ground Pressure9 psi
Track Gauge103 in
Number of Track Rollers per Side2
Max Travel Speed3.0 mph
Shoe Size24 in
Number of Shoes per Side50
Number of Carrier Rollers per Side9
Drawbar Pull54,904 lb

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth247 in
Max Reach Along Ground393 in
Max Loading Height265 in
Max Vertical Wall Digging Depth198 in
Max Cutting Height384 in
Shipping Length of Unit437 in
Shipping Height of Unit143 in
Minimum swing radius184 in
Max Digging Reach397 in
Max.Dumping Height268 in

Bucket

Bucket specifications
Reference Bucket Capacity2.00 yd³
Maximum Bucket Capacity2.50 yd³
Minimum Bucket Capacity1.60 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed10 rpm

Boom/Stick Excavator Option 2

Boom/Stick Excavator Option 2 specifications
Max Digging Depth264 in
Max Vertical Wall Digging Depth222 in
Max Cutting Height394 in
Max Loading Height272 in
Max Reach Along Ground408 in
Shipping Length of Unit432 in
Shipping Height of Unit142 in
Minimum swing radius183 in
Max Digging Reach414 in
Max.Dumping Height276 in

Boom/Stick Excavator Option 3

Boom/Stick Excavator Option 3 specifications
Max Digging Depth292 in
Max Cutting Height404 in
Max Loading Height283 in
Max Vertical Wall Digging Depth251 in
Max Reach Along Ground432 in
Shipping Length of Unit428 in
Shipping Height of Unit152 in
Minimum swing radius160 in
Max.Dumping Height287 in

Boom/Stick Excavator Option 4

Boom/Stick Excavator Option 4 specifications
Max Digging Depth323 in
Max Cutting Height415 in
Max Reach Along Ground461 in
Max Loading Height294 in
Max Vertical Wall Dig Depth281 in
Shipping Length of Unit432 in
