570
Processor
18 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 30,424 lb |
|---|---|
| Max Speed | 15.6 mph |
| Fuel Capacity | 79.3 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 140 A |
| Hydraulic System Fluid Capacity | 52.9 gal |
| Cooling System Fluid Capacity | 7.7 gal |
| Transmission Type | Hydrostatic mechanical with two speed gearbox |
Engine
| Engine Model | 6BTA5.9 |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 165.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged and aftercooled |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 512 lb-ft |
Dimensions
| Height - Top of Cab | 144 in |
|---|---|
| Wheelbase | 138 in |
| Overall Width | 110 in |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Ground Clearance | 24 in |
Boom
| Max Reach w/ Head | 393 in |
|---|
Drive System
| Tire Size - front | 700 x 26.5 ELS |
|---|---|
| Tire Size - rear | 750 x 26.5 TRS |
