John Deere
Caterpillar
554
Forwarder
33 specifications
John Deere
1110D
- Operating Weight - 8wd
- 38,140 lb
- Operating Weight - 6wd
- 30,137 lb
- Max Speed
- 13.7 mph
- Displacement
- 415 in³
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight - 8wd | 38,140 lb |
|---|---|
| Operating Weight - 6wd | 30,137 lb |
| Fuel Capacity | 40.0 gal |
| Hydraulic System Fluid Capacity | 39.6 gal |
| Alternator Supplied Amperage | 100 A |
| Operating Voltage | 24 V |
| Front/Rear Tire Size - 8wd | 600x26.5/20 / 600x26.5/20 |
| Front/Rear Tire Size - 6wd | 600x34/14 / 600x26.5/20 |
Engine
| Engine Model | JD6068 HTJ75 |
|---|---|
| Displacement | 415 in³ |
| Power Measured @ | 2,000 rpm |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,400 rpm |
| Power | 161.0 hp |
| Torque | 530 lb-ft |
Hydraulic System
| Pump Type | variable displacement |
|---|---|
| Relief Valve Pressure | 3,480 psi |
| Flow Capacity | 49.6 gal/min |
Dimensions
| Ground Clearance | 24 in |
|---|---|
| Wheelbase | 198 in |
| Width Over Tires | 107 in |
| Length | 383 in |
| Length of Bunk Area | 192 in |
| Width of Bunk Area | 101 in |
Transmission
| Max Speed | 13.7 mph |
|---|---|
| Transmission Type | hydrostatic/mechanical |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bunk
| Load Area | 17.19 yd³ |
|---|---|
| Load Weight - 8wd | 26,455 lb |
| Load Weight - 6wd | 26,455 lb |
Crane
| Max Reach | 284 in |
|---|---|
| Gross Lift Torque | 75,230 lb-ft |
| Crane Type | Timberjack CF 5 72 |
| Gross Slew Torque | 18,000 lb-ft |
