John Deere
Caterpillar
554
Forwarder
33 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight - 8wd | 38,580 lb |
|---|---|
| Fuel Capacity | 43.6 gal |
| Hydraulic System Fluid Capacity | 37.0 gal |
| Alternator Supplied Amperage | 140 A |
| Operating Voltage | 24 V |
| Front/Rear Tire Size - 8wd | 700x26.5/700x26.5 |
Engine
| Engine Model | 6068H |
|---|---|
| Displacement | 414 in³ |
| Power Measured @ | 2,000 rpm |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,400 rpm |
| Power | 173.0 hp |
| Torque | 575 lb-ft |
Hydraulic System
| Pump Type | variable displacement |
|---|---|
| Relief Valve Pressure | 3,480 psi |
| Flow Capacity | 55.5 gal/min |
Dimensions
| Ground Clearance | 24 in |
|---|---|
| Wheelbase | 230 in |
| Width Over Tires | 121 in |
| Length | 410 in |
| Length of Bunk Area | 214 in |
| Width of Bunk Area | 109 in |
Transmission
| Max Speed | 13.7 mph |
|---|---|
| Transmission Type | hydrostatic/mechanical |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bunk
| Load Area | 19.78 yd³ |
|---|---|
| Load Weight - 8wd | 30,865 lb |
Crane
| Max Reach | 284 in |
|---|---|
| Gross Lift Torque | 92,194 lb-ft |
| Crane Type | Timberjack CF 7 72 |
| Gross Slew Torque | 23,602 lb-ft |
