John Deere
Caterpillar
554
Forwarder
33 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Operating Weight - 8wd | 42,990 lb |
|---|---|
| Fuel Capacity | 48.0 gal |
| Hydraulic System Fluid Capacity | 50.0 gal |
| Alternator Supplied Amperage | 140 A |
| Operating Voltage | 24 V |
| Front/Rear Tire Size - 8wd | 750x26.5/750x26.5 |
Engine
| Engine Model | 6081H |
|---|---|
| Displacement | 494 in³ |
| Power Measured @ | 2,000 rpm |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,300 rpm |
| Power | 215.0 hp |
| Torque | 811 lb-ft |
Hydraulic System
| Pump Type | variable displacement |
|---|---|
| Relief Valve Pressure | 3,480 psi |
| Flow Capacity | 55.5 gal/min |
Dimensions
| Ground Clearance | 29 in |
|---|---|
| Wheelbase | 233 in |
| Width Over Tires | 126 in |
| Length | 427 in |
| Length of Bunk Area | 220 in |
| Height to Top of crane | 154 in |
| Width of Bunk Area | 117 in |
Transmission
| Max Speed | 14.3 mph |
|---|---|
| Transmission Type | hydrostatic/mechanical |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bunk
| Load Area | 23.20 yd³ |
|---|---|
| Load Weight - 8wd | 37,480 lb |
Crane
| Max Reach | 335 in |
|---|---|
| Gross Lift Torque | 111,370 lb-ft |
| Crane Type | Timberjack CF 8 85 |
| Gross Slew Torque | 30,240 lb-ft |
