John Deere
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight | 11,806 lb |
|---|---|
| Fuel Capacity | 13.3 gal |
| Tire Size | 365/70 R18 |
| Hydraulic System Fluid Capacity | 23.8 gal |
| Front Axle/Diff Fluid Capacity | 1.6 gal |
| Rear Axle/Diff Fluid Capacity | 1.6 gal |
| Rated Bucket Capacity | 0.99 yd³ |
Engine
| Engine Model | 4TNV98 |
|---|---|
| Displacement | 201 in³ |
| Net Power | 61.0 hp |
| Engine Make | YANMAR |
| Make | YANMAR |
| Torque | 176 lb-ft |
| Alternator | 80 A |
| System Voltage | 12 V |
| Rated Speed | 2,200 rpm |
| Transmission Type | Hydrostatic |
| Emission level | Tier 4 |
| Pump | Gear |
| Engine Output-Net | 61.0 hp |
Weights
| Operating Weight | 11,806 lb |
|---|
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 85 in |
| Width Over Tires | 70 in |
| Length with Bucket on Ground | 214 in |
| Turning clearance circle | 336 in |
Transmission
| Pump Flow | 70.0 gal/min |
|---|
Brakes & Steering
| Parking brake | Wet Disc |
|---|---|
| Brakes Type | Wet Disc & Drum |
| Actuation | Hydraulic |
Fluid Capacities
| Hydraulic Tank | 23.8 gal |
|---|---|
| Transmission | 0.3 gal |
| Heaped Capacity | 1.10 yd³ |
Bucket
| Dump Clearance at Max Raise | 96 in |
|---|
General Specifications
| Operating Weight | 11,806 (5,355) — Starting 2019 Model Year |
|---|---|
| Bucket Capacity | 1.0 - 1.4 (0.8 - 1.1) — Starting 2019 Model Year |
| Engine type | YANMAR 4TNV98 — Starting 2019 Model Year |
| Engine Power | 61 (45) — Starting 2019 Model Year |
| Max Dump Height | 8.0 (2.4) — Starting 2019 Model Year |
