John Deere
Yanmar
VIO17
Mini Excavator
19 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 6,394 lb |
|---|---|
| Fuel Capacity | 10.5 gal |
| Hydraulic Pump Flow Capacity | 16.4 gal/min |
| Hydraulic System Fluid Capacity | 9.2 gal |
Engine
| Engine Model | 3TNV88 |
|---|---|
| Displacement | 100 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 26.4 hp |
| Number of Cylinders | 3 |
| Aspiration | Natural |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 97 in |
| Length of Track on Ground | 60 in |
| Tail Swing Radius | 31 in |
| Width to Outside of Tracks | 61 in |
| Removal Counterweight Clearance | 23 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Max Travel Speed | 2.8 mph |
| Shoe Size | 12 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 103 in |
|---|---|
| Max Reach Along Ground | 184 in |
| Max Loading Height | 126 in |
| Shipping Length of Unit | 166 in |
| Max Cutting Height | 176 in |
| Shipping Height of Unit | 97 in |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
