SR130
Skid Steer Loader
16 specifications
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Operating Weight | 8,409 lb |
|---|---|
| Max Speed | 12.0 mph |
| Hydraulic System Fluid Capacity | 21.2 gal |
| Tire Size | 14 x 17.5 12 PR Extra Wall |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 70 A |
Engine
| Engine Model | E 5030HT |
|---|---|
| Displacement | 183 in³ |
| Power Measured @ | 2,800 rpm |
| Number of Cylinders | 5 |
| Aspiration | Turbocharged and intercooled |
| Torque Measured @ | 2,000 rpm |
| Engine Make | John Deere PowerTech |
| Air cleaner | Dry dual element |
| Emissions Certification | EPA Tier 3/EU Stage IIIA |
| Net Torque | 221 lb-ft |
| Net Torque Rise | — |
Hydraulic System
| Pump Flow Capacity | 32.3 gal/min |
|---|---|
| Hydraulic Horsepower-Standard Flow | 46.0 hp |
| Hydraulic Horsepower_High Flow | 77.0 hp |
| System Pressure at Couplers | 3,450 psi |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Reach at Max Lift and Dump | 31 in |
| Height - Top of ROPS/FOPS | 85 in |
| Length w/o Bucket | 119 in |
| Angle of departure | 31 ° |
| Length | 142 in |
| Hinge pin height, maximum height | 127 in |
| Turning Radius - TTS870 | 86 in |
Loader
| Operating Load Rating | 2,950 lb |
|---|---|
| Operating Width | 77 in |
| Tipping load (ISO 14397) | 5,600 lb |
| bucket breakout force (ISO 14397) | 7,750 lb |
| Boom breakout force | 5,000 lb |
| Width without Bucket | 77 in |
| Dump angle @ max. height | 45 ° |
| Dump height | 102 in |
| Rollback - Ground Level | 35 ° |
Axles
| Tractive Effort | 8,610 lb-ft |
|---|---|
| Maximum Axle Torque | 6,235 lb-ft |
