John Deere
Venieri
363F
Wheel Loader
22 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 18,870 lb |
|---|---|
| Fuel Capacity | 40.0 gal |
| Tire Size | 15.5-25 |
| Hydraulic System Fluid Capacity | 13.0 gal |
| Static Tipping Weight | 10,122 lb |
| Operating Voltage | 12 V |
| Turning Radius | 167 in |
| Engine Oil Fluid Capacity | 3.1 gal |
| Rear Axle Oscillation | 22 ° |
| Front Axle/Diff Fluid Capacity | 4.3 gal |
| Rear Axle/Diff Fluid Capacity | 4.3 gal |
| Cooling System Fluid Capacity | 8.1 gal |
| Transmission Fluid Capacity | 10.1 gal |
Engine
| Displacement | 329 in³ |
|---|---|
| Power Measured @ | 2,400 rpm |
| Gross Power | 95.0 hp |
| Net Power | 85.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Natural |
| Torque Measured @ | 1,400 rpm |
Hydraulic System
| Pump Flow Capacity | 39.5 gal/min |
|---|---|
| Relief Valve Setting | 2,250 psi |
| Pump Type | Engine driven vane |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 122 in |
| Wheelbase | 95 in |
| Length with Bucket on Ground | 260 in |
| Hinge Pin - Max Height | 134 in |
Transmission
| Max Speed - Forward | 22.5 mph |
|---|---|
| Max Speed - Reverse | 8.5 mph |
| Transmission Type | Powershift Planetary |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 2 |
