John DeereJohn Deere
315C
Backhoe Loader
47 specifications
1 / 5
Image 1 of 5
Specifications
56 data points
Operating Specifications
| Operating Weight 2wd | 23,038 lb |
|---|---|
| Fuel Capacity | 44.0 gal |
| Hydraulic System Fluid Capacity | 40.0 gal |
| Cooling System Fluid Capacity | 6.9 gal |
| Tire Size Front - 2wd / 4wd | 14.5/75-16.110PR F3 |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 5.1 gal |
| Alternator Supplied Amperage | 95 A |
| Turning Radius | 173 in |
| Transmission Fluid Capacity | 6.0 gal |
| Max Weight | 23,000 lb |
| Rear Axle Fluid Capacity | 4.5 gal |
Engine
| Engine Model | 6059T |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 120.0 hp |
| Net Power | 115.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Net Max Torque | 343 lb-ft |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 53.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,550 psi |
| Pump Type | Radial pistons |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Wheelbase | 95 in |
| Transport Width | 97 in |
| Transport Length | 320 in |
| Height to Top of Suspended Cab | 111 in |
Transmission
| Max Speed | 21.0 mph |
|---|---|
| Max Speed - Reverse | 6.6 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 2 |
| Transmission Type | Powershift |
Tires & Wheels
| Rear Tires Size | 21L-2416PR R4 |
|---|
General Specifications
| Operating Weight lbs (kg) | 23,000 (10,450) Starting 2004 Model Year |
|---|---|
| Lift Capacity lbs (kgs) | 7,733 (3,503) Starting 2004 Model Year |
| Loading Height ft (m) | 13.3 (4.03) Starting 2004 Model Year |
| 4th Gear Fwd mph (kmh) | 22 (30.6) Starting 2004 Model Year |
| Breakout Force lbs (kgs) | 14,050 (6,322) Starting 2004 Model Year |
| Digging Depth ft (m) | 18.2 (5.54) Starting 2004 Model Year |
| SAE Net hp (kW) | 115 (86) Starting 2004 Model Year |
Backhoe
| Dig Depth | 219 in |
|---|---|
| Reach From Swivel | 272 in |
| Dig Depth - Extended | 277 in |
| Load Height - Extended | 183 in |
| Bucket Dig Force | 12,940 lb |
| Reach From Swivel - Extended | 328 in |
| Reach at Load Height - Extended | 377 in |
| Bucket Dig Force - Extended | 12,940 lb |
Loader
| Bucket Capacity | 1.90 yd³ |
|---|---|
| Clearance at Max Dump Height | 114 in |
| Bucket Breakout Force | 14,050 lb |
| Bucket Width | 96 in |
| Reach at Max Dump Height | 335 in |
| Dig Depth | 6 in |
