John Deere
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Operating Weight | 63,875 lb |
|---|---|
| Fuel Capacity | 135.0 gal |
| Hydraulic Pump Flow Capacity | 144.2 gal/min |
| Hydraulic System Fluid Capacity | 87.0 gal |
| Hydraulic System Relief Valve Pressure | 4,050 psi |
| Engine Oil Capacity | 25.0 gal |
| Cooling System Fluid Capacity | 36.0 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 11.0 gal |
| Alternator Supplied Amperage | 42 A |
Engine
| Engine Model | 6466A |
|---|---|
| Displacement | 4,668 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 205.0 hp |
| Net Power | 195.0 hp |
| Aspiration | Turbocharged with aftercooler |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 827 lb-ft |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 119 in |
| Length of Track on Ground | 158 in |
| Tail Swing Radius | 130 in |
| Width to Outside of Tracks | 133 in |
| Removal Counterweight Clearance | 46 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Track Gauge | 102 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 2.5 mph |
| Shoe Size | 31 in |
| Number of Shoes per Side | 50 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 45,410 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 551 in |
|---|---|
| Max Reach Along Ground | 726 in |
| Max Loading Height | 522 in |
| Max Cutting Height | 607 in |
| Shipping Length of Unit | 552 in |
| Shipping Height of Unit | 172 in |
Bucket
| Reference Bucket Capacity | 0.99 yd³ |
|---|
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
