John Deere
992D LC
- Operating Weight
- 97,530 lb
- Max Digging Depth
- 287 in
- Max Digging Depth
- 323 in
- Net Power
- 265.0 hp
1 / 5
Image 1 of 5
Specifications
51 data points
Operating Specifications
| Operating Weight | 97,530 lb |
|---|---|
| Fuel Capacity | 145.0 gal |
| Hydraulic Pump Flow Capacity | 21.0 gal/min |
| Hydraulic System Fluid Capacity | 132.0 gal |
| Hydraulic System Relief Valve Pressure | 4,050 psi |
| Engine Oil Capacity | 36.0 gal |
| Cooling System Fluid Capacity | 36.0 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 5.6 gal |
| Alternator Supplied Amperage | 45 A |
Engine
| Engine Model | 6619A |
|---|---|
| Displacement | 619 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 275.0 hp |
| Net Power | 265.0 hp |
| Aspiration | Turbocharged aftercooled diesel |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 862 lb-ft |
Dimensions
| Ground Clearance | 30 in |
|---|---|
| Height - Top of Cab | 128 in |
| Length of Track on Ground | 176 in |
| Tail Swing Radius | 137 in |
| Width to Outside of Tracks | 144 in |
| Removal Counterweight Clearance | 53 in |
Undercarriage
| Ground Pressure | 9 psi |
|---|---|
| Track Gauge | 114 in |
| Shoe Size | 30 in |
| Number of Shoes per Side | 53 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 287 in |
|---|---|
| Max Reach Along Ground | 439 in |
| Max Loading Height | 272 in |
| Max Vertical Wall Digging Depth | 172 in |
| Max Cutting Height | 396 in |
| Shipping Length of Unit | 468 in |
| Shipping Height of Unit | 141 in |
Bucket
| Reference Bucket Capacity | 2.39 yd³ |
|---|
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 323 in |
|---|---|
| Max Vertical Wall Digging Depth | 276 in |
| Max Cutting Height | 435 in |
| Max Loading Height | 306 in |
| Max Reach Along Ground | 481 in |
| Shipping Length of Unit | 463 in |
| Shipping Height of Unit | 135 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 359 in |
|---|---|
| Max Cutting Height | 462 in |
| Max Loading Height | 340 in |
| Max Vertical Wall Digging Depth | 330 in |
| Max Reach Along Ground | 519 in |
| Shipping Length of Unit | 463 in |
| Shipping Height of Unit | 179 in |
