John Deere
Caterpillar
252
Skid Steer Loader
54 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 2,587 lb |
|---|---|
| Max Speed | 5.0 mph |
| Fuel Capacity | 11.0 gal |
| Hydraulic System Fluid Capacity | 15.0 gal |
| Tire Size | 8.50-27-15 4-ply-rating |
| Operating Voltage | 12 V |
| Engine Oil Fluid Capacity | 1.1 gal |
| Operating Speed | 5.0 mph |
Engine
| Displacement | 60 in³ |
|---|---|
| Power Measured @ | 3,600 rpm |
| Gross Power | 25.0 hp |
| Number of Cylinders | 2 |
Hydraulic System
| Pump Flow Capacity | 8.0 gal/min |
|---|---|
| Relief Valve Pressure | 1,500 psi |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Width Over Tires | 32 in |
| Reach at Max Lift and Dump | 15 in |
| Length with Bucket | 100 in |
| Clearance at Max Lift and Dump | 64 in |
| Turning Radius from Center - machine rear | 3 in |
| Length w/o Bucket | 72 in |
Loader
| Bucket Capacity | 0.30 yd³ |
|---|---|
| Operating Load Rating | 800 lb |
| Tipping Angle | 1,700 ° |
| Breakout Force | 1,500 psi |
