Kato
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
51 data points
Operating Specifications
| Operating Weight | 66,580 lb |
|---|---|
| Fuel Capacity | 148.0 gal |
| Hydraulic Pump Flow Capacity | 160.0 gal/min |
| Hydraulic System Fluid Capacity | 128.2 gal |
| Hydraulic System Relief Valve Pressure | 4,760 psi |
| Engine Oil Capacity | 13.0 gal |
| Cooling System Fluid Capacity | 14.2 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 3.0 gal |
| Alternator Supplied Amperage | 35 A |
Engine
| Engine Model | 6D24-TE1 |
|---|---|
| Displacement | 729 in³ |
| Power Measured @ | 1,700 rpm |
| Net Power | 232.0 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 745 lb-ft |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 120 in |
| Length of Track on Ground | 148 in |
| Tail Swing Radius | 137 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 46 in |
Undercarriage
| Ground Pressure | 9 psi |
|---|---|
| Track Gauge | 103 in |
| Max Travel Speed | 3.4 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 48 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 265 in |
|---|---|
| Max Reach Along Ground | 409 in |
| Max Loading Height | 281 in |
| Max Vertical Wall Digging Depth | 226 in |
| Max Cutting Height | 400 in |
| Shipping Length of Unit | 433 in |
| Shipping Height of Unit | 133 in |
Bucket
| Reference Bucket Capacity | 1.90 yd³ |
|---|
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 292 in |
|---|---|
| Max Vertical Wall Digging Depth | 258 in |
| Max Cutting Height | 407 in |
| Max Loading Height | 288 in |
| Max Reach Along Ground | 433 in |
| Shipping Length of Unit | 433 in |
| Shipping Height of Unit | 133 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 331 in |
|---|---|
| Max Cutting Height | 427 in |
| Max Loading Height | 306 in |
| Max Vertical Wall Digging Depth | 301 in |
| Max Reach Along Ground | 472 in |
| Shipping Length of Unit | 433 in |
| Shipping Height of Unit | 133 in |
