Kawasaki
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 15,146 lb |
|---|---|
| Fuel Capacity | 31.8 gal |
| Tire Size | 15.5-25-8PR(L2) |
| Hydraulic System Fluid Capacity | 19.9 gal |
| Turning Radius | 202 in |
| Engine Oil Fluid Capacity | 3.5 gal |
| Cooling System Fluid Capacity | 5.3 gal |
| Transmission Fluid Capacity | 3.5 gal |
Engine
| Engine Model | 4BD1-T |
|---|---|
| Displacement | 357 in³ |
| Power Measured @ | 2,250 rpm |
| Net Power | 87.0 hp |
| Aspiration | diesel w/ turbo |
Hydraulic System
| Raise Time | 5.4 s |
|---|---|
| Lower Time | 2.8 s |
| Dump Time | 1.0 s |
Dimensions
| Height - Top of Cab | 120 in |
|---|---|
| Wheelbase | 101 in |
| Reach at Max Lift and Dump | 39 in |
| Length with Bucket on Ground | 234 in |
Transmission
| Max Speed - Forward | 21.2 mph |
|---|---|
| Max Speed - Reverse | 21.2 mph |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 2.11 yd³ |
|---|---|
| Bucket Capacity - struck | 1.60 yd³ |
| Dump Clearance at Max Raise | 107 in |
| Breakout Force | 15,287 lb |
