JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight | 38,800 lb |
|---|
Engine
| Engine Model | HINO J05EUM-KSST |
|---|---|
| Displacement | 313 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 127.4 hp |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 356 lb-ft |
| Bore | 5 in |
| Stroke | 5 in |
| Engine Type | Direct injection |
| Emission Tier Level | Tier IV final-compliant engine |
Weights
| Operating Weight | 38,801 lb |
|---|
Hydraulic System
| Pump Type | Two variable displacement pumps + One gear pump |
|---|---|
| Boom cylinder | 4 in |
| Bucket cylinder | 5 in |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Overall Length | 343 in |
| Tail Swing Radius | 101 in |
| Track Gauge | 79 in |
| Overall width -Upper Structure | 102 in |
Undercarriage
| Max Travel Speed | 2.9 mph |
|---|
Fluid Capacities
| Fuel Tank | 74.0 gal |
|---|---|
| Hydraulic system | 52.9 gal |
| Engine Oil | 5.5 gal |
| Cooling system | 5.1 gal |
| Diesel exhaust fluid (DEF) tank | 9.0 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 256 in |
|---|---|
| Max Reach Along Ground | 372 in |
| Max Vertical Wall Digging Depth | 235 in |
| Max Digging Reach | 373 in |
| Max Digging Reach on Ground | 367 in |
| Bucket Digging Force - SAE | 22,706 lb |
| Max Digging Height | 385 in |
| Bucket Digging Force - ISO | 25,628 lb |
| Max Dumping Clearance | 280 in |
| Min Dumping Clearance | 85 in |
| Arm Crowd Force - SAE | 15,602 lb |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|---|
| Swing radius | 108 in |
