Kobelco

SK210D-10 CAR DEMO

Excavator

Operating Weight
66,139 lb
Net Power
160.0 hp
All excavators
Kobelco SK210D-10 CAR DEMO Excavator
1 / 5
Image 1 of 5
Image: farmersequip.com

Specifications

18 data points

Operating Specifications

Operating Specifications specifications
Operating Weight66,139 lb
Fuel Capacity84.5 gal
DEF tank capacity21.9 gal

Engine

Engine specifications
Engine ModelHINO J05EUM-KSSC
Displacement313 in³
Power Measured @2,000 rpm
Net Power160.0 hp
Torque Measured @1,600 rpm
Max Torque472 lb-ft
Bore5 in
Stroke5 in
Engine TypeDirect injection water-cooled 4-cycle diesel engine with turbocharger intercooler(Complies with EU (NRMM) Stage IV EPA Tier IV Final.

Dimensions

Dimensions specifications
Height - Top of Cab148 in
Tail Swing Radius115 in

Undercarriage

Undercarriage specifications
Ground Pressure10 psi
Max Travel Speed3.7 mph
Shoe Size24 in

General Specifications

General Specifications specifications
MaxPumpFlow116.3 gal/min
