KobelcoKobelco
SK350LC-10 H&W
Excavator
35 specifications
Kobelco
SK260LC-10 H&W
- Operating Weight
- 63,052 lb
- Max Digging Depth
- 253 in
- Max Digging Depth
- 289 in
- Net Power
- 178.0 hp
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Operating Weight | 63,052 lb |
|---|---|
| Fuel Capacity | 106.5 gal |
| DEF tank capacity | 21.9 gal |
Engine
| Engine Model | HINO J05EUN-KSSD |
|---|---|
| Displacement | 313 in³ |
| Power Measured @ | 2,100 rpm |
| Net Power | 178.0 hp |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 469 lb-ft |
| Engine Type | Direct injection water-cooled 4-cycle 4-cylinder diesel engine with intercooler turbo-charger |
Dimensions
| Ground Clearance | 32 in |
|---|---|
| Height - Top of Cab | 135 in |
| Tail Swing Radius | 122 in |
| Track Gauge | 113 in |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Max Travel Speed | 3.6 mph |
| Shoe Size | 28 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 253 in |
|---|---|
| Max Vertical Wall Digging Depth | 229 in |
| Minimum swing radius | 154 in |
| Max Digging Reach | 397 in |
| Max Digging Reach on Ground | 396 in |
| Max Digging Height | 400 in |
| Max Dumping Clearance | 285 in |
| Min Dumping Clearance | 115 in |
General Specifications
| MaxPumpFlow | 64.8 gal/min |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 289 in |
|---|---|
| Max Vertical Wall Digging Depth | 261 in |
| Minimum swing radius | 154 in |
| Max Digging Reach | 432 in |
| Max Digging Reach on Ground | 425 in |
| Max Dumping Clearance | 300 in |
| Min Dumping Clearance | 88 in |
| Max. digging height | 418 in |
| Horizontal Digging Stroke - Ground | 258 in |
